The durable Cobra 20" BMX bike is built with sealed front and rear hubs for less maintenance and a smooth ride. The Atom series 3-piece tubular chromoly cranks, aftermarket Eastern Riblet grips, Atom pedals, and Eastern tires give it that pro look and feel. Designed with a strong hi-tensile steel frame for long-lasting durability.
FEATURES
3pc Tubular Chromoly Atom Cranks
Sealed Bearing Front & Rear Hubs
Hi-Tensile Steel Frame
Hi-Tensile Steel Fork and Bars
Eastern Riblet Grips
Eastern Atom Pedals
Eastern Sprocket
MAXIMUM WEIGHT RECOMMENDATION : 135 kg
FRAME
Hi Tensile Steel Cobra 20"
Top Tube Size: 20"
BB: AM Loose Ball
Headtube: Aheadset
Chainstay Length: 13.38"
Clamp: Integrated with Frame
BARS
Hi-Ten 8.5"
Upsweep/Backsweep 12⁰/1⁰
FORK
Cobra - Chromoly Steerer with Hi-tensile steel Tapered legs, 3/8" dropouts
Fork Rake: 28mm
HEADSET Aheadset
STEM Forged Alloy Top Load Stem
GRIP Eastern Riblet Grips
CRANK 3-Piece, Tubular Heat-Treated Chromoly, Bolt for Sprocket, Pinch Bolt with 8-Splined Spindle, 170mm 28.6mm Round Arm
BOTTOM BRACKET American Loose Ball
CHAINWHEEL Eastern Phorcys, Cold Hard Steel, 25T
CHAIN KMC Z510 1/2 x 1/8
PEDAL Eastern Atom Plastic Pedal with 9/16" Axle
FRONT BRAKE N/A
FRONT LEVER N/A
REAR BRAKE U-Brake, Forged Alloy, Wide Body, Clear Brake Pads
REAR LEVER Forged Alloy Lever
BRAKE CABLE [S] LINEAR
SADDLE Padded Seat with Railed Supports
POST Steel 200mm
FRONT HUB Sealed Bearings, Forged Alloy Shell, Drilled for 36 Spokes, 3/8" Chromoly Axle
REAR HUB Sealed Bearings, Forged Alloy Shell Drilled for 36 Spokes, 14mm Chromoly Axle
FREEWHEEL 9 Tooth Sealed Driver with Hub
FRONT RIM Alloy, Single Wall, Drilled for 36 Spokes. For 20" Tires
REAR RIM Alloy, Single Wall, Drilled for 36 Spokes. For 20" Tires
SPOKES 14 Gauge with Brass Nipples
FRONT TIRE 20 x 2.3 *Specs subject to change
REAR TIRE 20 x 2.3 *Specs subject to change
*Bikes are designed for riders 13 years old and up.
